QD-OLED moves to RGB 'V-stripe' pixels for improved text clarity

After LG Display's move to RGB-stripe pixels in OLED, Samsung Display has announced the first QD-OLED panel with 'V-Stripe' RGB pixels.

The announcement was made in a press release by Samsung Display ahead of CES 2026 next week, where more details and panels will be revealed.

Samsung Display refers to it as 'V-Stripe' pixels.

- "The new V-Stripe structure aligns Red, Green, and Blue (RGB) sub-pixels vertically, shifting from the conventional triangular sub-pixel arrangement used in current QD-OLED technology. Developed independently by Samsung Display for quantum dot elements, the V-Stripe structure improves the clarity of text edges, making it ideal for users engaged in text-intensive tasks such as document editing, coding, or content creation," explained Samsung Display.

 Also read: Why text looks bad on the new OLED and QD-OLED monitors


What is V-Stripe QD-OLED?
While Samsung Display did not release any images of the new pixel structure in QD-OLED, a teaser from MSI gives an indication of the new layout, explaining why it is referred to as V-Stripe rather than just stripe.

As illustrated, the red subpixel is larger than the green, which in turn is larger than the blue, forming a 'V' shape. Samsung Display explains that the subpixels are aligned vertically ('V' for vertical).

MSI's illustration may differ slightly from the final subpixel layout. We are seeking additional details from Samsung Display.


First 2026 QD-OLED panel
Samsung Display confirmed that the first 2026 QD-OLED panel to use V-Stripe is a 34-inch 21:9 ultrawide panel with a 360Hz refresh rate, 0.03 ms response time, 1300 nits peak brightness (3%), 300 full-screen brightness, and 99% DCI-P3.

It also confirmed that this panel has been in mass production since December 2025. Initially, it will be supplied to 7 monitor makers, including Asus, MSI and Gigabyte, for their 2026 monitors.

- "The biggest technical challenges in mass-producing high refresh rate panels with a new pixel structure include reduced organic material lifespan, heat generation, and brightness degradation," said a Samsung Display spokesperson. "By leveraging QD-OLED's top emission structure, which offers brightness advantages, along with improvements in organic material efficiency and design optimization, we were able to mass-produce a high-performance monitor display that integrates four key features: the 'V-Stripe' pixel structure, an ultra-wide aspect ratio, a high refresh rate, and enhanced brightness."


QD-OLED holds a 75% share
Market research firm Omdia notes that OLED's share rose from 14% in 2024 to 23% in 2025 in the premium monitor segment (above $500), and is expected to increase further to 27% in 2026.

Improved OLED panels in 2026 are expected to accelerate the shift from aging LCD panels to OLED, giving users the opportunity to enjoy HDR picture quality and significantly better gaming performance.

QD-OLED is estimated to have held a 75% share of the OLED monitor panel market in 2025, with LG Display's WOLED a distant second.
